How much does a 743 Bobcat weight?
Here is what we know about the Bobcat 743 Skid Steer Loader. It has a Diesel Engine that produces 36 horsepower. This Bobcat 743 skid steer is a four cylinder and weighs 4600 pounds.
What years did they make 743 bobcat?
Bobcat 743 Specifications & Technical Data (1987-1991)
How much does a Bobcat skid steer weigh?
The weight of skid steers varies from types and brands. But typically, the range is between 1,500 – 12,000lbs. The average weight of a full-size skid steer is roughly 7,500lbs.
How much weight can a Bobcat 753 lift?
753 Skid Steer Loader Specifications
| Engine/Electrical | |
|---|---|
| Engine Cooling | Liquid |
| Performance | |
| Rated Operating Capacity (SAE) | 1300 lbs |
| Tipping Load | 2634 lbs |
How big is a Bobcat 743?
Dimensions. This skid steer loader is 120.4 inches long, 55.1 inches wide and 75.8 inches tall. It has a wheelbase of 35.4 inches. The bucket reach at maximum height is 21.8 inches, or a little less than 2 feet, which makes the Bobcat 743 unsuitable for loading trucks.
How much will a Bobcat 743 lift?
UNITS
| Engine Cooling | Liquid |
|---|---|
| Horsepower | 36 hp |
| Rated Operating Capacity ( SAE ) | 1,300 lbs |
| Tipping Load | 2600 lbs |
| Operating Weight | 4720 lbs |
How much hydraulic fluid does a 743 bobcat?
How much hydraulic fluid does a bobcat 743 hold?
| 743 FLUID CAPACITIES | UNITS |
|---|---|
| Fuel Capacity | 13 gals. (49 L) |
| Engine Oil With Filter | 9 qts (8.5 L) |
| Hydraulic/Hydrostatic System | 6 gal. (22.7 L) (Incl 3.5 gal in reservoir) |
| Chaincase Reservoir | 32 qts. (30.3 L) |
Can a half ton pull a skid steer?
Fortunately, many skid steer loaders can be moved using a half-ton or three-quarter-ton truck and appropriate trailer. Determining a reliable and safe means for hauling, requires examining the operating weight of your skid steer loader, the weight of the trailer, and the towing capacity of the tow vehicle.
How much can a Bobcat 743 lift?
What engine is in a Bobcat 743?
Engine. The Bobcat 743 loader uses a Kubota V1702 engine. This liquid-cooled, four-cylinder diesel engine produces 36 horsepower, according to the manufacturer. The engine displacement is 105.7 cubic inches.
What series is a Bobcat 743?
Rolling off the assembly line in 1981, the Bobcat 40 Series gave customers what they’d been waiting for — a loader with a larger frame size. The 843, along with the 743, built off the 30 Series’ success by improving serviceability, operator safety, durability and performance for new markets and applications.
What are the specs for a Bobcat skid steer?
Here are the Bobcat 763 Specs: Manufacturer: Bobcat. Model: 763. Type: Skid Steer Loader . Years manufactured: 1994-2002. Engine power: 46 HP – 34.3 kW. Rated operating capacity: 1500 lbs – 680 kg. Bucket width: 60 inches – 152 cm.
What is a Bobcat skid steer loader?
A skid loader, skid-steer loader, or skidsteer, is a small, rigid-frame, engine-powered machine with lift arms used to attach a wide variety of labor-saving tools or attachments.
What is a Bobcat skid?
Bobcat is a brand name. Bobcat offers skid steers and many other types of construction equipment. There are over a dozen models of Bobcat skid steers. Bobcat also offers more than 70 attachment options.
